Complete analyser for continuous pH, Redox (ORP) and temperature monitoring in pool water using dual-channel measurement.
This dual-channel monitor provides continuous, simultaneous measurement of pH and Redox (ORP) potential in pool water. Designed for real-time water quality monitoring, it ensures precise, reliable control of pool chemistry. The system features a rugged AMI pH/mV transmitter in an IP66-rated enclosure, a specialised flow cell with digital flow indicator, and an PT1000 temperature sensor. Factory-tested and ready for installation, it uses Swansensor pH and Redox electrodes for accurate readings.
Specifications
- Dual-channel transmitter for simultaneous pH, redox and temperature monitoring in pool water.
- Easy calibration without removing or disassembling the sensors.
- Flow cell with integrated sample flow detection and Pt1000 temperature sensor.
- Swansensor pH and Redox Standard electrodes provide precise, reliable measurements.
- Factory-tested and ready for installation and operation.
AMI-II Pool Specifications
The AMI-II Pool is a complete analyser for the automatic, continuous measurement of pH, redox potential (ORP) and temperature in pool water.
The system includes an AMI-II Dual pH/Redox transmitter in an IP66-rated aluminium enclosure, a specialised flow cell with integrated sample flow detection and a Pt1000 temperature sensor.
The dual-channel system measures pH and redox simultaneously, supporting reliable, real-time monitoring and control of pool water chemistry.
pH measurement
| Sensor | Swansensor pH Standard |
| Measuring range | pH 1.00 to 13.00 |
| Resolution | 0.01 pH |
| Reference temperature | 25 °C |
| Temperature compensation | Automatic according to Nernst |
Redox measurement
| Sensor | Swansensor Redox Standard |
| Measuring range | −1500 to +1500 mV |
| Resolution | 1 mV |
Temperature measurement
| Sensor | Pt1000, DIN Class A |
| Measuring range | −30 to +250 °C |
| Accuracy | ±0.25 °C from 0 to 50 °C |
| Resolution | 0.1 °C |
Sample conditions
| Flow rate | Minimum 30 L/h |
| Sample temperature | Maximum 50 °C |
| Operating pressure | Maximum 2 bar |
Sample connections
| Sample inlet | 8 mm Serto tube adapter, PA |
| Sample outlet | 8 mm Serto tube adapter, PA |
Power supply
| AC version | 100–240 VAC (±10%), 50/60 Hz (±5%) |
| Power consumption | Maximum 35 VA |
Panel
| Dimensions | 300 × 530 × 150 mm |
| Material | White PVC |
| Total weight | 5 kg |
Contact us to place an order.
Downloads
| Brochure | Product Flyer |
| Manual | Manual |
| Datasheet | Datasheet |
